Minifix C100 Spread Bolt 8/24mm Zinc Alloy Black - Plastic, Zinc Alloy Black, Chromated
Product Code: 262.09.202
Minifix C100 Spread Bolt 8/24mm Zinc Alloy Black - Plastic, Zinc Alloy Black, Chromated
Product Code: 262.09.202
334,200 In stock
£0.10
Ex. VAT: £0.08
Sold in packs of 100 — £9.67 per pack
This product is part of a range with 2 options. Select an option to filter, then choose the matching variant.
| Quantity | Pack Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 4 packs | £9.19 | Save 5% |
| 5 – 9 packs | £8.70 | Save 10% |
| 10+ packs | £7.74 | Save 20% |
- Products Description
- Technical Specifications
Article details
Excellent drive gives the PZ2 screwdriver a secure grip in the bolt head
For industry, joiners and cabinet makers.Connecting bolt for universal use within the Minifix® connector system with special benefits:Extremely installation-friendly, no tools are requiredNo surface damage caused by insertion and removal of spreading bolt
For drill hole Ø8 mm
Area of application
For one-sided installation and for industry, joiners and cabinetmakers
Bolt hole
8 mm
For wood thickness
≥15 mm
Häfele Lifetime Guarantee
25 years
Functionality
When the connector is tightened, the double cone in the bolt expands the sleeve and pushes the threads into the wood. The stronger the tightening force, the stronger the connection.
Additional information attributes
Due to the different types of panels, wood, constructions and tolerances, tests on the object are needed when high pull-out resistance is required
Excellent drive gives the PZ2 screwdriver a secure grip in the bolt head
For industry, joiners and cabinet makers.Connecting bolt for universal use within the Minifix® connector system with special benefits:Extremely installation-friendly, no tools are requiredNo surface damage caused by insertion and removal of spreading bolt
For drill hole Ø8 mm
Area of application
For one-sided installation and for industry, joiners and cabinetmakers
Bolt hole
8 mm
For wood thickness
≥15 mm
Häfele Lifetime Guarantee
25 years
Functionality
When the connector is tightened, the double cone in the bolt expands the sleeve and pushes the threads into the wood. The stronger the tightening force, the stronger the connection.
Additional information attributes
Due to the different types of panels, wood, constructions and tolerances, tests on the object are needed when high pull-out resistance is required
| Material | Plastic, Zinc alloy |
| Colour/Finish | Black, chromated |
| Drive | PZ2 cross slot |
| Threading | Spreading sleeve; length11.5 mm |
| Thread Type | Special thread |
| Installation | For toolless insertion and unscrewing and for press-fit installation in Ø 10 mm pre-drilled holes |
