Minifix S100 Con Bolt 3/5/34mm Steel Galvanised
Product Code: 262.28.919
Minifix S100 Con Bolt 3/5/34mm Steel Galvanised
Product Code: 262.28.919
1,100 In stock
£0.10
Ex. VAT: £0.09
Sold in packs of 100 — £10.33 per pack
This product is part of a range with 3 options. Select an option to filter, then choose the matching variant.
- Products Description
- Technical Specifications
Article details
For drill hole Ø3 mm
Area of application
For single or double-sided constructions
Bolt hole
8 mm
Häfele Lifetime Guarantee
25 years
Order reference
Expanding sleeves and dowels for Ø 5 mm holes are available to order separately
For drill hole Ø3 mm
Area of application
For single or double-sided constructions
Bolt hole
8 mm
Häfele Lifetime Guarantee
25 years
Order reference
Expanding sleeves and dowels for Ø 5 mm holes are available to order separately
| Material | Steel |
| Drive | PZ2 cross slot, Flat blade |
| Threading | Special thread; length12 mm |
| Thread Type | Special thread |
| Installation | For direct, screw-in installation in Ø 3 mm holes or for press-fitinstallation in Ø 5 mm holes when used with dowels |
