Traser-6 Cab Hanger 65kg Dowel RH SZP - Steel Zinc Plated
Product Code: 290.21.900
Traser-6 Cab Hanger 65kg Dowel RH SZP - Steel Zinc Plated
Product Code: 290.21.900
15,507 In stock
£2.00
Ex. VAT: £1.67
This product is part of a range with 2 options. Select an option to filter, then choose the matching variant.
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 19 | £2.00 | — |
| 20 – 49 | £1.91 | Save 5% |
| 50 – 99 | £1.80 | Save 10% |
| 100+ | £1.61 | Save 20% |
- Products Description
- Technical Specifications
Article details
Easy fixing using integrated lever
Product versionQuick fixing system with leverNot visible inside the cabinet
Area of application
Wall unit, concealed
130 kg
Mounting only with manual screwdriver.
Standard
The load bearing capacity of the cabinet hanger is 65 kg/piece in compliance with the DIN EN 68840 standard requirements.
Adjustment facility
Adjustment screws can be accessed from the front after installation
(1) Depth adjustment with 16 mm clearance
(2) Height adjustment 17 mm
Order reference
Wall plate or rail must be ordered separatelyPlease order Hospa Ø 4.0 mm screws separately
Additional information attributes
Mounting only with manual screwdriver.
Easy fixing using integrated lever
Product versionQuick fixing system with leverNot visible inside the cabinet
Area of application
Wall unit, concealed
130 kg
Mounting only with manual screwdriver.
Standard
The load bearing capacity of the cabinet hanger is 65 kg/piece in compliance with the DIN EN 68840 standard requirements.
Adjustment facility
Adjustment screws can be accessed from the front after installation
(1) Depth adjustment with 16 mm clearance
(2) Height adjustment 17 mm
Order reference
Wall plate or rail must be ordered separatelyPlease order Hospa Ø 4.0 mm screws separately
Additional information attributes
Mounting only with manual screwdriver.
| Material | Steel |
| Colour/Finish | zinc plated |
| Load bearing capacity | 65 kg; per pair |
| Installation | For press fitting; reference |
