Parliament Hinge 102x127mm Brass Polished Brass
Product Code: 921.08.590
Parliament Hinge 102x127mm Brass Polished Brass
Product Code: 921.08.590
7 In stock
£35.42
Ex. VAT: £29.52
This product is part of a range with 2 options. Select an option to filter, then choose the matching variant.
- Products Description
- Technical Specifications
- Dimensions
Article details
Brass pin
MountingFor DIN left and DIN right hand use
Door width max.1000 mm
Flange shapesquare
Model series
Butt hinge
Area of application
Suitable for lightweight applications only
For door type
Wooden door leaf, metal door
For frame type
Wooden frame, Metal frame
Max. door weight for 3 hinges
35 kg
Door thickness
≤1,000 mm
Bearing type
With fixed pin
Additional information attributes
Because of the short hinge knuckle this hinge can not sustain excessive loads or extra wide doors. If in doubt please consider extra wide projection hinges
Brass pin
MountingFor DIN left and DIN right hand use
Door width max.1000 mm
Flange shapesquare
Model series
Butt hinge
Area of application
Suitable for lightweight applications only
For door type
Wooden door leaf, metal door
For frame type
Wooden frame, Metal frame
Max. door weight for 3 hinges
35 kg
Door thickness
≤1,000 mm
Bearing type
With fixed pin
Additional information attributes
Because of the short hinge knuckle this hinge can not sustain excessive loads or extra wide doors. If in doubt please consider extra wide projection hinges
| Material | Brass |
| Supplied with | Fixing screws |
| Knuckle diameter | 13 mm |
| Flange height | 102 mm |
| Flange thickness | 5 mm |
