3832-EC FD BB Drawer Runner Full 45kg 450mm Black - Steel Black Zinc Plated
Product Code: 432.23.345
3832-EC FD BB Drawer Runner Full 45kg 450mm Black - Steel Black Zinc Plated
Product Code: 432.23.345
35 In stock
£43.72
Ex. VAT: £36.43
This product is part of a range with 2 options. Select an option to filter, then choose the matching variant.
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 1 | £43.72 | — |
| 2 – 3 | £41.41 | Save 5% |
| 4+ | £36.80 | Save 16% |
- Products Description
- Technical Specifications
Article details
Soft closing on last 45 mm of closing cyclePartially shielded mechanism prevents dust or debris from interfering with the operation12.7 mm slide thicknessHold-in feature holds the closed drawer inLever disconnect for easy installation and removalThe cam drawer adjust offers installers a simple, yet precise mechanism for vertical drawer adjustmentNot suitable for use with mounting brackets
Operating temperature range 10-40°C
Holding function
Hold-in
Removing the running track
With release lever
Order reference
Order Varianta Ø 5 cylindrical head and Hospa Ø 4.0 pan head screws separatelyFixings: Max. head height 2.5 mm, Ø 9.6 mm
Additional information attributes
Please note max.drawer width to be used. Drawer width should not exceed installed lengthNot for lateral file drawer applications or where the drawer is wider than it is deep
Soft closing on last 45 mm of closing cyclePartially shielded mechanism prevents dust or debris from interfering with the operation12.7 mm slide thicknessHold-in feature holds the closed drawer inLever disconnect for easy installation and removalThe cam drawer adjust offers installers a simple, yet precise mechanism for vertical drawer adjustmentNot suitable for use with mounting brackets
Operating temperature range 10-40°C
Holding function
Hold-in
Removing the running track
With release lever
Order reference
Order Varianta Ø 5 cylindrical head and Hospa Ø 4.0 pan head screws separatelyFixings: Max. head height 2.5 mm, Ø 9.6 mm
Additional information attributes
Please note max.drawer width to be used. Drawer width should not exceed installed lengthNot for lateral file drawer applications or where the drawer is wider than it is deep
| Material | Steel |
| Colour/Finish | Black zinc plated |
| Installation | Side mountingDrawer width must not exceed slide length |
