Symo3000 Gls Dr Lever Lockcase B MNP - Zinc Alloy Nickel Plated, Nickel Plated Polished
Product Code: 233.42.710
Symo3000 Gls Dr Lever Lockcase B MNP - Zinc Alloy Nickel Plated, Nickel Plated Polished
Product Code: 233.42.710
11 In stock
£15.32
Ex. VAT: £12.77
This product is part of a range with 4 options. Select an option to filter, then choose the matching variant.
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 9 | £15.32 | — |
| 10 – 19 | £14.56 | Save 5% |
| 20 – 49 | £13.79 | Save 10% |
| 50+ | £12.26 | Save 20% |
- Products Description
- Technical Specifications
Article details
Closure directions can be altered by re-positioning the cam, but always moving in the same direction*:Closure direction A can be altered to D, F or GClosure direction B can be altered to C, E or HClosure travel: 90º locking cam (reversible), 180º key
Area of application
For cylinder cores that are inserted from the front on site
Suitable for
With straight locking cam
Version
With straight cam
For glass thickness
4 – 10 mm
with key
No
Order reference
Please order counterpiece for 2-leaf sliding doors separately.
Additional information attributes
The locks can be operated by turning the protective cap with a screwdriver or coin, before the cylinder cores are installed
Closure directions can be altered by re-positioning the cam, but always moving in the same direction*:Closure direction A can be altered to D, F or GClosure direction B can be altered to C, E or HClosure travel: 90º locking cam (reversible), 180º key
Area of application
For cylinder cores that are inserted from the front on site
Suitable for
With straight locking cam
Version
With straight cam
For glass thickness
4 – 10 mm
with key
No
Order reference
Please order counterpiece for 2-leaf sliding doors separately.
Additional information attributes
The locks can be operated by turning the protective cap with a screwdriver or coin, before the cylinder cores are installed
| Material | Zinc alloy |
| Colour/Finish | Nickel plated, Nickel plated polished |
| Closure travel | 180° |
| Supplied with | 1 Locking cam1 Mounting nut1 Angledsteel striking plate1 Clamping plate1 Clamping plastic rosette |
| Installation | Right hand |
| Cylinder shape | prepared for round cylinder |
