Cylinder Cam Lock 22mm PNP H1 Dir.B 235.91.826

Cylinder Cam Lock 22mm PNP H1 Dir.B - Brass Nickel Plated, Polished

Name: Cylinder Cam Lock 22mm PNP H1 Dir.B - Brass Nickel Plated, Polished
Brand: Hafele
SKU: 235.91.826
Price: 32.77 GBP
Availability: InStock

Product Code: 235.91.826

Cylinder Cam Lock 22mm PNP H1 Dir.B - Brass Nickel Plated, Polished

Product Code: 235.91.826

Download Brochure

Browse more Budget & Cabinet Locks

5 In stock

£32.77

Ex. VAT: £27.31

Closing direction:

Type of locking:

For door thickness:

Key change:

This product is part of a range with 7 options. Select an option to filter, then choose the matching variant.

Quantity	Unit Price (inc. VAT)	You Save
1 – 1	£32.77	—
2 – 3	£31.04	Save 5%
4+	£27.60	Save 16%

Products Description
Technical Specifications

Article details
With key trap; key can only be removed in locked position
With 5 pairs of pins = 10,000 possible key changesClosure directions can be altered by re-positioning the cam, but always moving in the same direction:Closure direction A can be altered to D, F or GClosure direction B can be altered to C, E or H
Locking systemStandard profile
For door thickness≤ 18 mm
Version
Straight locking cam
Type of locking
with 5 pin tumblers
Order reference
Order spacer bushes and anti-twist washer separately

Material	Brass
Colour/Finish	Nickel plated, Polished
Threading	length L18 mm
Closure travel	90° (reversible, with key trap)
Supplied with	1 Cam lock2 Keys1 Locking cam3 Nuts1 washerSecurity pass and locking plan with locking systems
Installation	For screw fixing with hexagonal nut(aperture pattern 19 x 16 mm)
