Mitred Flap Hinge 135D for 45D App - Cup: Zinc Alloy, Hinge Arm: Steel Cup: Nickel Plated
Product Code: 325.00.708
Mitred Flap Hinge 135D for 45D App - Cup: Zinc Alloy, Hinge Arm: Steel Cup: Nickel Plated
Product Code: 325.00.708
2 In stock
£24.73
Ex. VAT: £20.61
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 4 | £24.73 | — |
| 5 – 9 | £23.42 | Save 5% |
| 10+ | £20.82 | Save 16% |
- Products Description
- Technical Specifications
- Dimensions
Area of application: For 45° mitre applications
For door material: Wood
Material: Cup: Zinc alloy, Hinge arm: Steel
Colour/finish: Cup: nickel plated
Opening angle: 135°
For door thickness: 16 – 22 mm
Side panel thickness: 16 – 20 mm
Adjustment facility: Adjustable up to 3 mm in 3 directions
Installation: For screw fixing
Installation note: Provide 2 mm door gap all round.The edge must be chamfered by 3 mm from a side panel thickness of 20 mm.
Order reference: Order Hospa Ø 3.5 mm raised head screws separately
For door material: Wood
Material: Cup: Zinc alloy, Hinge arm: Steel
Colour/finish: Cup: nickel plated
Opening angle: 135°
For door thickness: 16 – 22 mm
Side panel thickness: 16 – 20 mm
Adjustment facility: Adjustable up to 3 mm in 3 directions
Installation: For screw fixing
Installation note: Provide 2 mm door gap all round.The edge must be chamfered by 3 mm from a side panel thickness of 20 mm.
Order reference: Order Hospa Ø 3.5 mm raised head screws separately
| Adjustment facility | Adjustable up to 3 mm in 3 directions |
| Area of application | For 45° mitre applications |
| For door material | Wood |
| Installation note | Provide 2 mm door gap all round.The edge must be chamfered by 3 mm from a side panel thickness of 20 mm. |
| Order reference | Order Hospa Ø 3.5 mm raised head screws separately |
| Material | Cup: Zinc alloy, Hinge arm: Steel |
| Colour/Finish | Cup: nickel plated |
| Opening angle | 135° |
| Installation | For screw fixing |
| For door thickness | 16 – 22 mm |
| Side panel thickness | 16 – 20 mm |
