Nexis 95D Hinge Clk INS Sprung Hos - Steel Nickel Plated
Product Code: 322.11.532
Nexis 95D Hinge Clk INS Sprung Hos - Steel Nickel Plated
Product Code: 322.11.532
3,614 In stock
£6.49
Ex. VAT: £5.41
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 9 | £6.49 | — |
| 10 – 29 | £6.17 | Save 5% |
| 30 – 49 | £5.84 | Save 10% |
| 50+ | £5.20 | Save 20% |
Required to complete this product
These items must be ordered separately.
- Products Description
- Technical Specifications
- Dimensions
Article details
For standard applications⌀ 35 mm cup
Soft-close compatible
Area of applicationFor standard applications
Concealed hinge versionInset
Crank typeHigh Cranked
Door processing for assemblywith cup drilling
Cup drilling Ø35 mm
Cup fixingfor screw fixing
Order reference
Wider range of mounting plates available, please order separatelyOrder Hospa ⌀ 3.5 mm raised head countersunk screws separately
For standard applications⌀ 35 mm cup
Soft-close compatible
Area of applicationFor standard applications
Concealed hinge versionInset
Crank typeHigh Cranked
Door processing for assemblywith cup drilling
Cup drilling Ø35 mm
Cup fixingfor screw fixing
Order reference
Wider range of mounting plates available, please order separatelyOrder Hospa ⌀ 3.5 mm raised head countersunk screws separately
| Material | Steel |
| Colour/Finish | nickel plated |
| Opening angle | 95° |
| Drilling pattern | 48/9 |
| Cup drilling depth | 11.8 mm |
