Tectus TE640 3D A8 180D Energy Hinge MN - Aluminium, Steel, Zinc, Die-cast
Product Code: 924.17.756
Tectus TE640 3D A8 180D Energy Hinge MN - Aluminium, Steel, Zinc, Die-cast
Product Code: 924.17.756
Out of Stock
Back in stock: 04/12/2026
£691.31
Ex. VAT: £576.09
This product is part of a range with 3 options. Select an option to filter, then choose the matching variant.
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 1 | £691.31 | — |
| 2 – 3 | £654.92 | Save 5% |
| 4+ | £582.16 | Save 16% |
- Products Description
- Technical Specifications
Article details
With permanent energy transferMaintenance free friction bearingsSuitable for left or right hand applicationsMax. door weight adjusted 160 kg
Area of application
For wooden, steel or aluminium framesFor flush doors
Door thickness
≥40 mm
Adjustment facility
3-way continuous adjustment: Vertical: ± 3 mm, Horizontal: ± 3 mm, Depth: ± 1.0 mm
With permanent energy transferMaintenance free friction bearingsSuitable for left or right hand applicationsMax. door weight adjusted 160 kg
Area of application
For wooden, steel or aluminium framesFor flush doors
Door thickness
≥40 mm
Adjustment facility
3-way continuous adjustment: Vertical: ± 3 mm, Horizontal: ± 3 mm, Depth: ± 1.0 mm
| Material | Aluminium, Steel, Zinc, Die-cast |
| Opening angle | 180 ° |
| Supplied with | Fixings |
