103 Series Overhead Fire Door Closer - Power Size 3-6 - Push/Pull Mounting - Black - Aluminium
Product Code: 699552P
103 Series Overhead Fire Door Closer - Power Size 3-6 - Push/Pull Mounting - Black - Aluminium
Product Code: 699552P
5 In stock
£120.90
Ex. VAT: £100.75
This product is part of a range with 4 options. Select an option to filter, then choose the matching variant.
- Products Description
- Technical Specifications
High-performance, power-adjustable door closer engineered for durability and dependable control in demanding commercial and residential environments
Suitable for up to 180° figure 1 opening – ideal where maximum door access and flexibility are required
Power adjustable size EN 3–6 – allows accurate on-site setting to suit various door sizes and installation requirements
Adjustable backcheck – helps cushion the door on opening, reducing impact and protecting surrounding walls and hardware
Fully adjustable closing speed to ensure smooth, controlled and reliable door operation
Supplied with a cover in a black finish for a clean, modern appearance
Suitable for doors up to 120kg maximum door weight
EN1154 performance tested and EN1634 fire tested – certified for dependable operation and approved for fire door use
Suitable for use on fire-resisting doorsets rated 30, 60, 90 and 120 minutes when installed in accordance with the tested doorset configuration and manufacturer’s instructions
Suitable for up to 180° figure 1 opening – ideal where maximum door access and flexibility are required
Power adjustable size EN 3–6 – allows accurate on-site setting to suit various door sizes and installation requirements
Adjustable backcheck – helps cushion the door on opening, reducing impact and protecting surrounding walls and hardware
Fully adjustable closing speed to ensure smooth, controlled and reliable door operation
Supplied with a cover in a black finish for a clean, modern appearance
Suitable for doors up to 120kg maximum door weight
EN1154 performance tested and EN1634 fire tested – certified for dependable operation and approved for fire door use
Suitable for use on fire-resisting doorsets rated 30, 60, 90 and 120 minutes when installed in accordance with the tested doorset configuration and manufacturer’s instructions
Product Specifications
| Arm Finish | Black |
| Backcheck | With Backcheck |
| Cam Action | No |
| CE Rated | CE Rated |
| Certifire | No |
| Duty | Heavy Duty |
| Finish | Black |
| Fire Rating | 30/60/90 & 120 |
| Material | Aluminium |
| Max Door Weight (kg) | 120kg |
| Option | Fig 66 - Push/Pull Side Mounting |
| Range | 103 Series |
| Type | Closer - Overhead |
| Max Door Width (mm) | 1400mm |
| Delayed Action | Without Delayed Action |
| Power Size | EN 3-6 |
| UKCA Approved | No |
| Track Arm | No |
| Brand | Eclipse |
| Cover | With Cover |
| Guarantee | 10 Years |
