AnyDoor Modular Door Hinge Router Jig - Aluminium

Fully-adjustable modular routing jig designed to quickly and accurately recess square and 10mm radius hinges in timber doors & frames
Modular rail construction allows the jig to be shortened or extended to suit smaller or oversized doors
Ideal for Dutch/stable doors, loft conversions, access panels, loft hatches and understairs storage
Patented twin-rail system provides unlimited hinge positions within the rail, making the jig perfect for both new and replacement installations
Radius hinge compatibility allows fast and accurate installation of square or 10mm radius hinge profiles
Bradawl or screw attachment options enables the jig to be secured with either bradawls for speed (included) or 3.5mm (no.6) woodscrews for maximum stability
Accommodates both full-height (1981mm/2040mm) and custom smaller doors
Adjustable edge guides accommodate 19mm, 26mm and 30mm hinge leaf widths (preset) or any leaf width between 12.7mm and 35mm (custom)
Adjustable quick-release aperture blocks feature Trend’s tool-free, patented thumb-turn locking mechanism for fast, accurate hinge positioning
3mm (1/8”) Steel End Plate ensures consistent head clearance and provides rapid door-to-frame transition
25mm (1”) Rail Depth allows jig to be used against fixed door stops
Includes: 3" rails (x2), 2" rails (x2), 1'6" rails (x2), hinge blocks (x6), end blocks, connectors (x6), bradawls (x6), 16mm guide bush, tough carry case
Requires: 12mm long-reach Router Cutter and 8mm (1/4") Plunge Router
Trend reference code: H/JIG/D6
