Radius Ball Bearing Grade 13 Butt Fire Door Hinge - 102 x 76 x 3mm - Satin Brass - Pair - 201 Stainless Steel
Product Code: 691774P
Radius Ball Bearing Grade 13 Butt Fire Door Hinge - 102 x 76 x 3mm - Satin Brass - Pair - 201 Stainless Steel
Product Code: 691774P
39 In stock
£11.09
Ex. VAT: £9.24
This product is part of a range with 8 options. Select an option to filter, then choose the matching variant.
- Products Description
- Technical Specifications
Heavy duty fire door hinges perfect for timber and steel doors up to 120kg
Unique welded cap system for increased durability
Smooth ball bearing operation reduces wear and provides a quieter operation
Saves installation time with quality fixings included
CE, UKCA & Certifire approved
BS EN Grade 13
Fire Rating: 30, 60, 90 & 120 minute timber fire doors & 240 minute steel fire doors
Unique welded cap system for increased durability
Smooth ball bearing operation reduces wear and provides a quieter operation
Saves installation time with quality fixings included
CE, UKCA & Certifire approved
BS EN Grade 13
Fire Rating: 30, 60, 90 & 120 minute timber fire doors & 240 minute steel fire doors
Product Specifications
| British Standard | Yes |
| BSEN Grade | 13 |
| CE Rated | CE Rated |
| Certifire | Yes |
| Corners | Radius |
| Duty | Heavy Duty |
| Finish | Satin Brass |
| Fire Rating | 30/60/90/120 & 240 |
| Length (mm) | 102mm |
| Material | 201 Stainless Steel |
| Max Door Weight (kg) | 120kg |
| Option | Ball Bearing |
| Pack Quantity | 2 |
| Size (mm) | 102 x 76 x 3mm |
| Type | Butt Hinge |
| Finish Group | Brass |
| Use | Interior |
| Size Range (mm) | 4 Inch/100mm |
| Steel Rating | 201 |
| Brand | Eclipse |
| Guarantee | 5 Years |
